- Display Unit: Liquid crystal display with two rows of 16 digits
- Keyboard: Four-key membrane keyboard
- Number of dispensing channels: 1, 2 or 4 channels
- Manifold Types: 8- or 16-way for parallel processing of 8- or 16-wells.
- Outside dimensions for plate washing: Width: 27.5 cm; depth: 36.6 cm; height: 18.5 cm
- Weight: 6.6kg
- Color: White (standard), Metallic red, Metallic blue
- Volume of solution dispensed:
- 50-3,000 µl in 50 µl steps (washing)
- 50-400 µl in 50 µl steps (dispensing)
- Dispensing Accuracy: ≤1.2 % typical (300 µl dispense volume, dispense rate: 3, 8-way manifold)
- Residual volume: Crosswise aspiration: ≤1.8 μl per well typical (96-well, flat-bottom Greiner® Bio-One plate) (asp. rate: 3; asp. time: 4 sec; head speed: 10 mm/sec; 8-way manifold)
- Interface: USB
- Shaking: Linear shaking; high, medium and low settings
- Power Supply: Auto Sensing for the settings 100-120V or 220-240V, 50/60 Hz
- Consumption: 65VA
** Specifications are subject to change. Typical performance values represent the average observed factory tested values.
