- Speed Range: 200 rpm – 16010 rpm; 10 rpm / increments, Angle Rotor: 16010 rpm, Swing out Rotor: 4600 rpm
- Maximum Relative Centrifuge Force (x g): 26361 x g; 10 x g / increments, Angle Rotor: 26361 x g, Swing out Rotor: 5204 x g
- Maximum Capacity (rotor): Angle Rotor: 6 x 250 ml Swing out: 4 x 1000 ml
- Refrigeration Range: -20 °C to 40 °C (1 °C/increments)
- Ambient temperature: 5 °C up to 35 °C
- Max. relative humidity: Max. relative humidity 80 % for temperatures up to 31 °C/Decreasing linearly to 50 % relative humidity up to 35 °C.
- Refrigerant: R290 (Propane)
- Running Time: Quick Spin, 10 sec to 99 hr 59 min, or continuous
- Noise Level: ≤63 + 2 dB(A)
- Acc/Dec Levels: 10/10
- Allowable Density at Maximum Speed: 1.2 g/ml
- Allowable Kinetic Energy: 70412 Nm
- AC Power: 230 V/50-60 Hz
- Voltage Fluctuation: ± 10%
- Current Consumption: 13A
- Power Consumption: 2.3 kW
- Dimensions (WxDxH): 24.4 x 27.2 x 38.6 in (620 x 690 x 980 mm)
- Shipping Dimensions (WxDxH): 36.6 x 30.7 x 49.6 in (930 x 780 x 1260 mm)
- Net Weight (without rotor): 419 lb/190 kg
- Shipping Weight (without rotor): 496 lb/225 kg
- For indoor use only
- Use up to an altitude of 2000 m
|
Tube Type |
Tube Dimensions | # of tubes per centrifuge |
| Microtubes |
5 ml (Ø 16.5 × 69 mm) |
96 |
| Blood Collection Tubes |
1.8 – 5 ml (Ø 13 × 75 mm) |
192 |
|
4 – 7 ml (Ø 13 × 100 mm) |
192 |
|
|
6 – 10 ml (Ø 16 × 100 mm) |
152 |
|
| Conical Tubes |
15 ml (Ø 17 × 120 mm) |
96 |
|
50 ml (Ø 29 × 116 mm) |
40 |
|
|
175 ml (Ø 61 × 118 mm) |
8 |
|
|
225 ml (Ø 61 × 137 mm) |
8 |
|
| 250 ml (Ø 60 × 159 mm) |
4 |
|
|
500 ml (Ø 97 × 148 mm) |
4 |
|
|
Vials & Bottles |
15 ml Round Bottom (Ø 17 × 120 mm) |
72 |
|
50 ml Round Bottom (Ø 29 × 116 mm) |
40 |
|
|
100 ml Round Bottom (Ø 44 × 100 mm) |
12 |
|
|
250 ml Flat Bottom (Ø 62 × 122 mm) |
8 |
|
|
290 ml Flat Bottom (Ø 62 × 137 mm) |
8 |
|
|
500 ml Flat Bottom (Ø 98 x 114 mm) |
4 |
|
|
750 ml Flat Bottom (Ø 98 x 152 mm) |
4 |
|
|
1000 ml Flat Bottom (Ø 98 x 172 mm) |
4 |
*Not suitable for use in hazardous environments.
