Name: Migali EVO-U35-ULTA -86C Ultra-low Temperature Freezer | 3.5 cu. ft. (100 Liters)
Brand: Migali
SKU: EVO-U35-ULTA
Availability: InStock

Migali EVO-U35-ULTA -86C Ultra-low Temperature Freezer | 3.5 cu. ft. (100 Liters)

Item#: EVO-U35-ULTA

Suitable for use in blood banks, hospitals, health and disease prevention systems, research institutions, colleges & universities, the electronic industry, biological engineering, laboratories in colleges & universities, military enterprises, deep-sea fishing companies, etc.

~~$10,116.00~~ $7,785.00

REQUEST PROPOSAL

Supplier: Migali

Cabinet Type: Upright
Capacity (L): 100
Internal Size (W*D*H): 450 x 450 x 514mm
External Size(W*D*H): 1066 x 742 x 820mm
Package Size(W*D*H): 1230 x 833 x 991mm (Packed in ordinary buckle cases)
NW/GW(Kgs): 131/175(wood packing)
Temperature Range: -40～-86 ℃
Ambient Temperature: 16-32℃
Cooling Performance: -80℃
Climate Class: N
Controller: Microprocessor
Display: Digital display
Compressor: 1pc
Cooling method: Direct Cooling
Defrost Mode: Manual
Refrigerant: Mixture Gas
Insulation Thickness- L: 91.5 R: 115
External Material: Cold rolled steel sheet
Inner Material: Stainless Steel
Shelves: 1 (stainless steel)
Door Lock with key: Yes
Padlock: Yes
Access Port: 1pc. Ø 25 mm
Casters: 4
Data Logging/Interval/Recording Time: USB/Record every 10 minutes / 12 months
Backup Battery: Yes
Temperature Alarm: High/Low temperature, High ambient temperature, Condenser overheating
Electrical Alarm: Power failure, Low battery
System Alarm: Sensor failure, Door ajar, Built-in USB datalogger failure, Communication error
Power Supply (V/Hz): 110/60
Remote alarm contact, RS485

Precise Temperature Control and Safe Storage- Microprocessor-based temperature controller, -40℃~-86℃ can be set freely with display accuracy at 0.1℃.
Visual & Audio Alarm system- High/low temperature alarm, power failure alarm, low battery alarm, door ajar alarm, high ambient
temperature alarm, communication failure alarm etc.
Refrigeration System- Applied Secop (Danfoss) compressor, 1 unit to reduce noise and improve the cooling temperature
come to -86℃ stably; Fan electromotor with internationally famous of Germany EBM, energy saving, high efficiency, and quiet.
Energy Saving- Equipped with DC/DC power management module, optimized energy saving; High-precision voltage control, stabilizing the voltage and freezer performance reduce the redundancy heat, completely eradicate overheating risk.
High-precision Temperature Control:
- Digital temperature display; display inner temperature, power and voltage, ambient temperature and more at the same time.
- 2 inches high-brightness digital temperature display, microprocessor-based temperature controller, -40℃~-86℃ can be set freely.
Alarm system
- The perfect audible & visual alarm system: High/low temperature , sensor failure, power failure , low battery ,door ajar , high ambient temperature, communication failure etc
- Startup delay and stop interval protection function to ensure reliable operation
- Keyboard lock and password protection function to prevent arbitrary adjustment of operating parameters
- Safety door lock design, ensure safety sample storage.
Refrigeration System
- Applied Secop (Primary Danfoss) compressor, 1 unit to reduce noise and improve the cooling performance
- Gasket surrounded with hot gas pipe for better defrost
- With 110mm foaming insulation including Vacuum Isolated Panel for high-efficiency cooling performance.
Insulation System
- 110mm foaming insulation with VIP board for better temperature performance
- Perfectly lock air conditioning, effectively prevent the loss of cooling capacity.
Human-oriented
- 4 universal casters for easy handing;
- Front opening lockable door with full height handle, with vacuum release port for easy open during cooling operation.
