- Gas service: Oxygen
- Body: Chrome-plated brass
- Flowtube: Polycarbonate
- Compensation: 50 PSIG (3.5 BAR)
- Conformances: FDA-listed; CRN OF15806.5
Ordering Information:
| Part Number | Description | Flowmeter Range (@ 50 PSIG) |
|---|---|---|
| 8052081-01-1 | Medical Oxygen Flowmeter with 1/4 in MNPT Inlet Connection and DISS 1240 Outlet Connection |
1-8 LPM |
| 8052082-01-1 | Medical Oxygen Flowmeter with 1/8 in FNPT Inlet Connection and DISS 1240 Outlet Connection |
1-8 LPM |
| 8052151-01-1 | Medical Oxygen Flowmeter with 1/4 in MNPT Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052152-01-1 | Medical Oxygen Flowmeter with 1/8 in FNPT Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052201 | Flowmeter Inlet Adapter for Medical Oxygen with Diamond Long Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052204 | Flowmeter Inlet Adapter for Medical Oxygen with Med Star Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052205 | Flowmeter Inlet Adapter for Medical Oxygen with Schrader Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052207 | Flowmeter Inlet Adapter for Medical Oxygen with Union Gland Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052208 | Flowmeter Inlet Adapter for Medical Oxygen with Union Nut Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052209 | Flowmeter Inlet Adapter for Medical Oxygen with NGC Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052210 | Flowmeter Inlet Adapter for Medical Oxygen with Hand-I-Twist Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052211 | Flowmeter Inlet Adapter for Medical Oxygen with Puritan Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052212 | Flowmeter Inlet Adapter for Medical Oxygen with OES Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052213 | Flowmeter Inlet Adapter for Medical Oxygen with Diamond Short Inlet Connection and 1/8 in MNPT Outlet Connection |
N/A |
| 8052270-01-1 | Medical Oxygen Flowmeter with Hand-I-Twist Inlet Connection and DISS 1240 Outlet Connection |
1-8 LPM |
| 8052275-01-1 | Medical Oxygen Flowmeter with Diamond Long (Ohmeda) Inlet Connection and DISS 1240 Outlet Connection |
1-8 LPM |
| 8052277-01-1 | Medical Oxygen Flowmeter with Puritan Inlet Connection and DISS 1240 Outlet Connection |
1-8 LPM |
| 8052290-01-1 | Medical Oxygen Flowmeter with Hand-I-Twist Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052291-01-1 | Medical Oxygen Flowmeter with Union Nut and Gland Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052293-01-1 | Medical Oxygen Flowmeter with Med Star Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052294-01-1 | Medical Oxygen Flowmeter with Diamond Short Inlet (with Ohmeda Power Outlet Extension) and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052295-01-1 | Medical Oxygen Flowmeter with Diamond Long (Ohmeda) Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052296-01-1 | Medical Oxygen Flowmeter with 1/8 in OES Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052297-01-1 | Medical Oxygen Flowmeter with Puritan Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052298-01-1 | Medical Oxygen Flowmeter with Diamond Short (Ohmeda) Inlet Connection and DISS 1240 Outlet Connection |
1-15 LPM |
| 8052299-01-1 | Medical Oxygen Flowmeter with NCG (Allied) Inlet Connection and DISS 1240 Outlet Connection |
<1-15 LPM |
