- Max working pressure: 1000 PSIG (70 BAR) or greater
- Inner core: Stainless steel
- Low profile braid: 304 stainless steel
- Armor flex casing: 304L stainless steel
- Minimum burst pressure: 5500 PSIG (380 BAR)
- Minimum bend radius: 6 in (152 mm)
- Inner diameter: 0.5 in
- Outer diameter: 1.0 in
- Temperature range: -450°F to 1500°F (-265°C to 815°C)
- Conformances: Cleanliness meets or exceeds CGA G-4.1; CRN OD18143.5
Ordering Information:
| Part Number | Description | Max Inlet Pressure |
|---|---|---|
| 5290245 | 4 ft (1.2 m) Cryogenic Hose for Liquid Oxygen featuring 304 Stainless Steel CGA 440 x 5/8 in Female Flare Cylinder Connections (both ends) | 1375 PSIG (95 BAR) |
| 5290246 | 5 ft (1.5 m) Cryogenic Hose for Liquid Oxygen featuring 304 Stainless Steel CGA 440 x 5/8 in Female Flare Cylinder Connections (both ends) | 1375 PSIG (95 BAR) |
| 5290247 | 6 ft (2 m) Cryogenic Hose for Liquid Oxygen featuring 304 Stainless Steel CGA 440 x 5/8 in Female Flare Cylinder Connections (both ends) | 1375 PSIG (95 BAR) |
| 5290248 | 10 ft (3 m) Cryogenic Hose for Liquid Oxygen featuring 304 Stainless Steel CGA 440 x 5/8 in Female Flare Cylinder Connections (both ends) | 1375 PSIG (95 BAR) |
| 5290249 | 12 ft (3.6 m) Cryogenic Hose for Liquid Oxygen featuring 304 Stainless Steel CGA 440 x 5/8 in Female Flare Cylinder Connections (both ends) | 1375 PSIG (95 BAR) |
| 5290250 | 4 ft (1.2 m) Cryogenic Hose for Liquid Nitrogen and Argon featuring 304 Stainless Steel CGA 295 x 1/2 in Female Flare Cylinder Connections (both ends) | 1330 PSIG (92 BAR) |
| 5290251 | 5 ft (1.5 m) Cryogenic Hose for Liquid Nitrogen and Argon featuring 304 Stainless Steel CGA 295 x 1/2 in Female Flare Cylinder Connections (both ends) | 1330 PSIG (92 BAR) |
| 5290252 | 6 ft (1.8 m) Cryogenic Hose for Liquid Nitrogen and Argon featuring 304 Stainless Steel CGA 295 x 1/2 in Female Flare Cylinder Connections (both ends) | 1330 PSIG (92 BAR) |
| 5290253 | 10 ft (3 m) Cryogenic Hose for Liquid Nitrogen and Argon featuring 304 Stainless Steel CGA 295 x 1/2 in Female Flare Cylinder Connections (both ends) | 1330 PSIG (92 BAR) |
| 5290254 | 12 ft (3.6 m) Cryogenic Hose for Liquid Nitrogen and Argon featuring 304 Stainless Steel CGA 295 x 1/2 in Female Flare Cylinder Connections (both ends) | 1330 PSIG (92 BAR) |
| 5290266 | 4 ft (1.8 m) Cryogenic Hose for Liquid Carbon Dioxide featuring Brass CGA 622 x 1/4 in FNPT Cylinder Connections (both ends) | 1000 PSIG (70 BAR) |
| 5290267 | 6 ft (3.6 m) Cryogenic Hose for Liquid Carbon Dioxide featuring Brass CGA 622 x 1/4 in FNPT Cylinder Connections (both ends) | 1000 PSIG (70 BAR) |
| 5290268 | Liquid Cylinder Withdrawal Adapter featuring Brass CGA 622 x 1/2 in MNPT |
